Sketch
Sketch helps you to analyze the frequency spektrum and the resonant peaks of a didgeridoo geometry. Find out more about how to read its outputs in this blog post
Usage Instructions
Enter the geometry of the didgeridoo in the text area. Each line should contain two numbers separated by a space. The first number is the position along the didgeridoo, and the second number is the diameter at that position. All dimensions are noted in millimeters.
Example:
0 32 [ Mouthpiece is position 0, 32 mm diameter] 100 34 [ at a 100mm mark 34mm wide] 200 38 1400 38Functionalities:
- Hit the "Analyze" button to start calculation.
- Hit the "Save" button to save the geometry to a txt file.
- Hit the "Load" button to load a txt file with geometry.
- Hit the "Load Shape" button to load a predefined shape from the repositories.
